SpitLight DPSS DRY
.png.png?s=D6A2BEF4F646F40CC91106C4DD2B2AE333041363)
The new Spitlight DPSS DRY laser by InnoLas Laser GmbH is an evolution of the well-established DPSS laser models. Key feature of the “DPSS DRY” laser is a cooling concept based on peltier technology enabling to operate the laser without any internal and external cooling water circuit. Furthermore, the laser comes with an all-in-one design with all components integrated into one housing.
| Repetition Rate | Pulse Energy (@ 1064 nm) |
Pulse Energy (@ 532 nm) |
Pulse Energy (@355 nm) |
Max. Avg. Power (@ 1064 nm) |
Stability RMS (@ 1064 nm) |
|
|---|---|---|---|---|---|---|
| DPSS DRY I | 10 Hz | > 80 mJ | > 40 mJ | > 20 mJ | 0.8 W | < 0.3 % |
| DPSS DRY II | 10 Hz | > 150 mJ | > 80 mJ | > 50 mJ | 1.5 W | < 0.3 % |
- No internal / external water cooling
- All-in-one: integrated power supply
- Low voltage supply input
- Wide temperature range available, down to -10°C
- Robust and stable monolithic design
- Easy to integrate
- Seeder
- Energy monitor
- Pointing laser
- External shutter
- Mechanical customization
