SpitLight Standard
Rugged and flexible design built in a monolithic housing with small footprint.
400 to 1000 mJ can be reached with this flash-lamp pumped laser series.
400 to 1000 mJ can be reached with this flash-lamp pumped laser series.
| Repetition Rate | Pulse Energy (1064 nm) |
Pulse Energy (532 nm) |
Pulse Energy (355 nm) |
Pulse Energy (266 nm) |
Stability RMS (1064 nm) |
|
|---|---|---|---|---|---|---|
| Standard 400-10 | 10 Hz | > 400 mJ | > 240 mJ | > 120 mJ | > 50mJ | < 0.7 % |
| Standard 400-20 | 20 Hz | > 350 mJ | > 210 mJ | > 100 mJ | > 40 mJ | < 0.9 % |
| Standard 400-30 | 30 Hz | > 300 mJ | > 180 mJ | > 80 mJ | > 30 mJ | < 1.0 % |
| Standard 400-50 | 50 Hz | > 200 mJ | > 100 mJ | > 40 mJ | > 25 mJ | < 1.5 % |
| Repetition Rate | Pulse Energy (1064 nm) |
Pulse Energy (532 nm) |
Pulse Energy (355 nm) |
Pulse Energy (266 nm) |
Stability RMS (1064 nm) |
|
|---|---|---|---|---|---|---|
| Standard 500-10 | 10 Hz | > 500 mJ | > 300 mJ | > 150 mJ | > 50 mJ | < 0.7 % |
| Standard 500-20 | 20 Hz | > 400 mJ | > 240 mJ | > 100 mJ | > 50 mJ | < 0.9 % |
| Standard 500-30 | 30 Hz | > 300 mJ | > 180 mJ | > 60 mJ | > 30 mJ | < 1.0 % |
| Repetition Rate | Pulse Energy (1064 nm) |
Pulse Energy (532 nm) |
Pulse Energy (355 nm) |
Pulse Energy (266 nm) |
Stability RMS (1064 nm) |
|
|---|---|---|---|---|---|---|
| Standard 600-10 | 10 Hz | > 800 mJ | > 480 mJ | > 240 mJ | > 90 mJ | < 0.7 % |
| Standard 600-20 | 20 Hz | > 700 mJ | > 420 mJ | > 150 mJ | > 60 mJ | < 0.9 % |
| Standard 600-30 | 30 Hz | > 650 mJ | > 380 mJ | > 120 mJ | > 50 mJ | < 1.0 % |
| Standard 600-50 | 50 Hz | > 550 mJ | > 320 mJ | > 90 mJ | > 40 mJ | < 1.5 % |
| Repetition Rate | Pulse Energy (1064 nm) |
Pulse Energy (532 nm) |
Pulse Energy (355 nm) |
Pulse Energy (266 nm) |
Stability RMS (1064 nm) |
|
|---|---|---|---|---|---|---|
| Standard 1000-10 | 10 Hz | > 1000 mJ | > 600 mJ | > 320 mJ | > 100 mJ | < 0.7 % |
| Standard 1000-20 | 20 Hz | > 900 mJ | > 550 mJ | > 300 mJ | > 100 mJ | < 1.0 % |
| Standard 1000-30 | 30 Hz | > 800 mJ | > 450 mJ | > 250 mJ | > 100 mJ | < 1.5 % |
- Compact laser head and power supply with small footprint
- Robust and stable resonator structure
- Quick and easy change of fl ashlamps
- Maintenance-free pumping chamber with ceramic refl ector
- Excellent beam quality and pointing stability
- Long fl ashlamp lifetime
- Double pulse option available
- System can be injection seeded (SLM-Option)
- Uniform super gaussian beam profi le available
- energy monitor (display in software available)
- injection seeding
- beam profile optimization (e.g. uniform super gaussian)
- attenuator (manual or motorized)
- flexible resonator design (e.g. stable or instable)
- multi-pulse option: pulse separation times as low as 100ns
- fifth harmonic available
- various cooling options available depending on repetition rate
- customization possible
