MAGNA
Based on the patented resonator design of the picolo series and the industry-proof amplifier design of the SpitLight family, the MAGNA platform creates sub-nanosecond pulses with up to 2 Joule pulse energy, with a peak power of 4 Gigawatt. Customized amplifier designs are also available.
| Repetition Rate | Pulse Energy (1064 nm) |
Pulse Energy (532 nm) |
Pulse Energy (355 nm) |
Stability RMS (1064 nm) |
Pulse Width (1064 nm) |
|
|---|---|---|---|---|---|---|
| MAGNA S | 1 - 20 Hz | > 100 mJ | > 60 mJ | > 30 mJ | < 1.2 % | < 600 ps |
| MAGNA I | 1 - 20 Hz | > 400 mJ | > 240 mJ | > 100 mJ | < 1.2 % | < 600 ps |
| MAGNA II | 1 - 20 Hz | > 1000 mJ | > 600 mJ | > 300 mJ | < 1.2 % | < 600 ps |
| MAGNA III | 1 - 10 Hz | > 2000 mJ | > 1000 mJ | > 500 mJ | < 1.2 % | < 600 ps |
- High energy: uo to 2 J at 500 ps pulse width
- High peak power: up to 4 Giga-Watt
- Sub-nanosecond oscillator and amplifier integrated in monolithic housing
- Active Q-switch, < 400 ps jitter
- High-energy sub-nanosecond pulses enable new experiments
- Quick and easy exchange of flashlamps
- Maintenance-free pumping chambers with ceramic reflector
- Excellent beam quality and pointing stability
- Integrated Harmonic Modules for frequency conversion down to 213nm
- Attenuator with Software integration
- Energy Monitors with Software integration
